| Brand Name: | AWX |
| Model Number: | 1203 1204 1205 1206 1207 |
| MOQ: | 10 |
| Price: | Negotiate |
| Packaging Details: | single box |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Aligning ball bearing has two kinds of structure, cylindrical hole and conical hole, cage material issteel plate, synthetic resin and so on. lt is characterized by the spherical raceway of the outer ringwith automatic centering, which can compensate for the error caused by different concentricity andshaft deflection, but the relative inclination of the inner and outer ring shall not exceed 3 degreesMainly bear radial load, while can bear small axial load. The axial displacement of the shaft(housing) is limited within the clearance limit, with automatic aligning performance, allowing theinternal and external relative tilt is not large under the condition of normal work, suitable forsupporting the seat hole can not strictly ensure the coaxiality of the parts.
Self-aligning: Aligning ball bearings have spherical inner and outer rings, allowing them to automatically adapt to misalignment caused by installation errors or shaft bending, reducing friction during operation.
Strong load capacity: Aligning ball bearings can withstand large radial loads and can handle certain axial loads, making it suitable for heavy-duty applications and environments with significant vibrations.
Easy installation: Due to its self-aligning feature, the alignment requirements during installation are relatively low, reducing installation difficulty and time.
Wide applicability: Aligning ball bearings are widely used in various industrial equipment, including electric motors, agricultural machinery, and construction machinery.
Low friction coefficient: The friction coefficient is relatively low, ensuring smooth operation and suitability for high-speed applications.
Long service life:Aligning ball bearings have a long service life, effectively reducing maintenance costs.
| Product name | High Quality Self-Aligning Ball Bearing,Mining Machinery Motor Motorcycle Auto Bearing |
| Trademark (brand) | AWX |
| port | Qingdao |
| Services | Provide OEM services. |
| payment method | L/C or T/T or D/P or Paypal |
| Feature | Long Life, High Speed, Low Noise,Small friction resistance, not easy to damage |
| Aligning Ball Bearings | ||||
| Bearing No. | Dimensions(mm) | Weight(kg) | ||
| d | D | B | ||
| 1203 | 17 | 40 | 12 | 0.076 |
| 1204 | 20 | 47 | 14 | 0.12 |
| 1205 | 25 | 52 | 15 | 0.14 |
| 1206 | 30 | 62 | 16 | 0.23 |
| 1207 | 35 | 72 | 17 | 0.32 |
| 1208 | 40 | 80 | 18 | 0.42 |
| 1209 | 45 | 85 | 19 | 0.47 |
| 1210 | 50 | 90 | 20 | 0.525 |
| 1211 | 55 | 100 | 21 | 0.705 |
| 1212 | 60 | 110 | 22 | 0.9 |
| 1213 | 65 | 120 | 23 | 1.15 |
| 1214 | 70 | 125 | 24 | 1.26 |
| 1215 | 75 | 130 | 25 | 1.36 |
| 1216 | 80 | 140 | 26 | 1.67 |
| 1217 | 85 | 150 | 28 | 2.07 |
| Bearing No. | Dimensions(mm) | Weight | ||
| d | D | B | kg | |
| 1303 | 17 | 47 | 14 | 0.13 |
| 1304 | 20 | 52 | 15 | 0.163 |
| 1305 | 25 | 62 | 17 | 0.257 |
| 1306 | 30 | 72 | 19 | 0.387 |
| 1307 | 35 | 80 | 21 | 0.51 |
| 1308 | 40 | 90 | 23 | 0.715 |
| 1309 | 45 | 100 | 25 | 0.957 |
| 1310 | 50 | 110 | 27 | 1.21 |
| 1311 | 55 | 120 | 29 | 1.58 |
| 1312 | 60 | 130 | 31 | 1.96 |
| 1313 | 65 | 140 | 33 | 2.45 |
| 1314 | 70 | 150 | 35 | 2.99 |
| 1315 | 75 | 160 | 37 | 3.56 |
| 1316 | 80 | 170 | 39 | 4.18 |
| 1317 | 85 | 180 | 41 | 4.98 |
| Bearing No. | Dimensions(mm) | Weight | ||
| d | D | T | kg | |
| 2203 | 17 | 40 | 16 | 0.09 |
| 2204 | 20 | 47 | 18 | 0.14 |
| 2205 | 25 | 52 | 18 | 0.163 |
| 2206 | 30 | 62 | 20 | 0.26 |
| 2207 | 35 | 72 | 23 | 0.403 |
| 2208 | 40 | 80 | 23 | 0.51 |
| 2209 | 45 | 85 | 23 | 0.55 |
| 2210 | 50 | 90 | 23 | 0.6 |
| 2211 | 55 | 100 | 25 | 0.81 |
| 2212 | 60 | 110 | 28 | 1.09 |
| 2213 | 65 | 120 | 31 | 1.46 |
| 2214 | 70 | 125 | 31 | 1.62 |
| 2215 | 75 | 130 | 31 | 1.62 |
| 2216 | 80 | 140 | 33 | 2.01 |
| 2217 | 85 | 150 | 36 | 2.52 |
| Bearing No. | Dimensions(mm) | Weight | ||
| d | D | T | kg | |
| 2303 | 17 | 47 | 19 | 0.158 |
| 2304 | 20 | 52 | 21 | 0.209 |
| 2305 | 25 | 62 | 24 | 0.335 |
| 2306 | 30 | 72 | 27 | 0.5 |
| 2307 | 35 | 80 | 31 | 0.675 |
| 2308 | 40 | 90 | 33 | 0.925 |
| 2309 | 45 | 100 | 36 | 1.23 |
| 2310 | 50 | 110 | 40 | 1.64 |
| 2311 | 55 | 120 | 43 | 2.1 |
| 2312 | 60 | 130 | 46 | 2.6 |
| 2313 | 65 | 140 | 48 | 3.23 |
| 2314 | 70 | 150 | 51 | 4.23 |
| 2315 | 75 | 160 | 55 | 5.13 |
| 2316 | 80 | 170 | 58 | 6.1 |
| 2317 | 85 | 180 | 60 | 7.05 |
Aligning ball bearings have various applications in different industries. Their ability to handle misalignment and provide reliable support makes them an essential component in various machinery and equipment.
Aligning ball bearings are often used in industrial machinery such as manufacturing equipment, conveyors, and assembly lines. They ensure a smooth operation even when there is a misalignment of shafts.
Aligning ball bearings are also commonly found in agricultural equipment such as tractors, harvesters, and other farming machinery. These machines may have varying alignment due to operational conditions, and aligning ball bearings help maintain smooth operation despite the misalignment.
Aligning ball bearings are utilized in various automotive applications such as engines, transmissions, and wheel hubs. They can tolerate misalignment, which improves the performance and longevity of the equipment.
Aligning ball bearings are essential in pumps used in fluid handling and compressors for gas applications. They allow for vibration and movement without equipment failure.
Aligning ball bearings are employed in robotic arms and automated machinery where precise movement is vital, but alignment can be challenging. They facilitate smooth operation despite the misalignment.
Aligning ball bearings have various applications in spinning machines, weaving looms, and paper mills. They help handle shifting loads and maintenance of high-speed operations.
Aligning ball bearings are commonly found in processing and packaging machinery used in the food and beverage industry. Cleanliness and reliability are crucial in this industry, and aligning ball bearings help maintain these standards despite the frequent misalignments.
Aligning ball bearings are implemented in conveyors, crushers, and other heavy machinery used in harsh environments, where misalignment is frequent.
Aligning ball bearings are used in heavy equipment like excavators, loaders, and cranes to ensure reliability and productivity on construction sites.
Aligning ball bearings are employed in fans and blowers used in HVAC systems. They ensure consistent airflow and efficiency despite the shift in alignment due to thermal expansion and vibration.
Aligning ball bearings are utilized in rolling stock and trains where wheels and axles require stable support under variable alignment conditions. They provide reliable support and ensure smooth operation despite misalignment.
Aligning ball bearings are also used in electric motors and generators to facilitate smooth rotation while accommodating slight misalignments.
Product Packaging:
Shipping:
Q: What is the brand name of the aligning ball bearings?
A: The brand name of the aligning ball bearings is AWX.
Q: Where are the aligning ball bearings manufactured?
A: The aligning ball bearings are manufactured in China.
Q: What is the minimum order quantity for the aligning ball bearings?
A: The minimum order quantity for the aligning ball bearings is 10.
Q: How much do the aligning ball bearings cost?
A: The price of the aligning ball bearings is negotiable.
Q: What are the payment terms for the aligning ball bearings?
A: The payment terms for the aligning ball bearings are L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
Q: How are the aligning ball bearings packaged?
A: The aligning ball bearings are packaged in a single box.
Q: What is the delivery time for the aligning ball bearings?
A: The delivery time for the aligning ball bearings is 30 days.
Q: What is the supply ability of the aligning ball bearings?
A: The supply ability of the aligning ball bearings is 10000pcs.
|
