| Brand Name: | AWX |
| Model Number: | 61824 |
| MOQ: | 10pcs |
| Packaging Details: | carton |
Thin wall bearings are typically constructed from high-quality materials such as stainless steel, chrome steel, or ceramic to ensure durability and reliability. They are engineered to handle both radial and axial loads and are available in various configurations, including deep groove, angular contact, and four-point contact designs, to suit different application requirements.
Compact Design: Thin wall bearings have a slim and lightweight construction, allowing them to be used in applications where space-saving is crucial.
High Precision: These bearings are designed to provide precise and accurate motion control, making them ideal for applications that require exact positioning and smooth operation.
Low Friction: Thin wall bearings are engineered to minimize friction and energy consumption, resulting in efficient performance and reduced wear and tear.
High Load Capacity: Despite their slim profile, thin wall bearings can handle significant radial and axial loads, ensuring reliable operation under heavy-duty conditions.
Durability: Made from high-quality materials, such as stainless steel or ceramic, thin wall bearings are durable and resistant to corrosion, ensuring a long service life.
Quiet Operation: Thin wall bearings are designed to operate quietly, making them suitable for applications where noise levels need to be kept to a minimum.
Easy Installation: These bearings are typically easy to install and maintain, offering convenience and cost-effectiveness in industrial settings.
| model | Imperial Sizes(in) | Metric Sizes | Radial load capacity | weight | |||||
| Inner diameter | Outer diameter | Width | Inner diameter | Outer diameter | Width | Static load | Dynamic load | (Kg) | |
| d | D | B | d | D | B | Cor | Cr | ||
| mm | mm | (N) | |||||||
| 61802 | 1000802 | 15 | 24 | 5 | 2.1 | 1.30 | 30000 | 22000 | |
| 61803 | 1000803 | 17 | 26 | 5 | 2.2 | 1.50 | 28000 | 20000 | |
| 61804 | 1000804 | 20 | 32 | 7 | 3.5 | 2.20 | 24000 | 18000 | |
| 61801 | 1000801 | 12 | 21 | 5 | 1.9 | 1.00 | 32000 | 24000 | |
| 61809 | 1000809 | 45 | 58 | 7 | 6.4 | 5.60 | 12000 | 9000 | |
| 61806 | 1000806 | 30 | 42 | 7 | 4.7 | 3.60 | 17000 | 13000 | |
| 61807 | 1000807 | 35 | 47 | 7 | 4.9 | 4.00 | 15000 | 11000 | |
| 61805 | 1000805 | 25 | 37 | 7 | 4.3 | 2.90 | 20000 | 16000 | |
| 61808 | 1000808 | 40 | 52 | 7 | 5.1 | 4.40 | 13000 | 10000 | |
| 61810 | 1000810 | 50 | 65 | 7 | 6.6 | 6.10 | 10000 | 8500 | |
| 61811 | 1000811 | 55 | 72 | 9 | 9.1 | 8.40 | 9500 | 8000 | |
| 61815 | 1000815 | 75 | 95 | 10 | 12.5 | 12.8 | 7000 | 6000 | |
| 61813 | 1000813 | 65 | 85 | 10 | 11.9 | 11.5 | 8000 | 6700 | |
| 61814 | 1000814 | 70 | 90 | 10 | 12.1 | 11.9 | 7500 | 6300 | |
| 61812 | 1000812 | 60 | 78 | 10 | 9.1 | 8.70 | 8500 | 7000 | |
| 61816 | 1000816 | 80 | 100 | 10 | 12.7 | 13.3 | 6700 | 5600 | |
| 61800 | 1000800 | 10 | 19 | 5 | 1.8 | 0.93 | 36000 | 28000 | |
| 61818 | 1000818 | 90 | 115 | 13 | 19.5 | 20.5 | 6000 | 4800 | |
| 61819 | 1000819 | 95 | 120 | 13 | 19.8 | 21.3 | 5600 | 4500 | |
| 61820 | 1000820 | 100 | 125 | 13 | 20.1 | 22.0 | 5300 | 4300 | |
| 61817 | 1000817 | 85 | 110 | 13 | 19.2 | 19.8 | 6300 | 5000 | |
| 61822 | 1000822 | 110 | 140 | 16 | 28.1 | 30.7 | 5000 | 3800 | |
| 61824 | 1000824 | 120 | 150 | 16 | 28.9 | 32.9 | 4300 | 3400 | |
| 61821 | 1000821 | 105 | 130 | 13 | 20.3 | 22.7 | 5000 | 4000 | |
| 61826 | 1000826 | 130 | 165 | 18 | 37.9 | 42.9 | 4000 | 3200 | |
Robotics: Thin wall bearings are often used in robotic arms, automated manufacturing systems, pick-and-place machines, and other robotic applications that require precise motion control and compact design.
Medical Equipment: Thin wall bearings are utilized in medical devices such as surgical instruments, imaging equipment, robotic surgery systems, and prosthetic devices where precision, reliability, and compactness are essential.
Aerospace: Thin wall bearings are used in aerospace applications such as aircraft landing gear, flight control systems, avionics, and satellite mechanisms where lightweight construction and high performance are critical requirements.
Automotive: Thin wall bearings find applications in automotive components such as steering systems, drive shafts, transmissions, and electric power steering systems to provide compact, lightweight, and durable solutions for vehicle operation.
Industrial Machinery: Thin wall bearings are employed in various industrial machinery and equipment, including textile machines, printing presses, packaging machinery, and semiconductor manufacturing equipment, where space constraints and precise motion control are important considerations.
Electronics and Semiconductor: Thin wall bearings are used in precision instruments, semiconductor manufacturing equipment, PCB drilling machines, and other electronic devices where precise positioning and stability are required for high-precision processes.
Renewable Energy: Thin wall bearings are employed in renewable energy applications such as solar tracking systems, wind turbines, and tidal energy devices to support the precise movement and alignment of components for optimal energy generation.
Product Packaging:
The thin wall bearings are packaged in a sturdy cardboard box to protect them during shipping and storage. Each bearing is individually wrapped in a plastic bag to prevent any damage or contamination during transportation.
Shipping:
Our thin wall bearings are shipped via a reputable courier service to ensure fast and reliable delivery to our customers. We take great care in packaging and labeling each shipment to ensure that it arrives in good condition and is easy to identify.
Q:What's your after-sales service and warranty?
A: We promise to bear the following responsibilities when defective products were found:
1. Replacements would be sent with goods of your next order;
2. Refund for defective products if customers require.
Q:Do you accept ODM&OEM orders?
A: Yes, we provide ODM&OEM services to worldwide customers, we also customize OEM box and packing as your requirements.
Q:What's the MOQ?
A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders.
Q:How long is the lead time?
A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days.
Q:Do you offer free samples?
A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight. We DO NOT offer free samples to end users.
Q:How to place order?
A: 1. Email us the model, brand and quantity,shipping way of bearings and we will quote our best price for you;
2. Proforma Invoice made and sent to you as the price agreed by both parts;
3. Deposit Payment after confirming the PI and we arrange production;
4. Balance paid before shipment or after copy of Bill of Loading.
|
