Angular Contact Ball Bearing

High Speed Angular Contact Ball Bearing Double Row 3200ATN9 3201ATN9 3202ATN9 3302ATN9

All Category

High / Low Temperature Resistant Bearings

Thrust Roller Bearing

Mr. li

awxnsy@precise-bearings.com

+86 198 1976 7739

Contact Now

High Speed Angular Contact Ball Bearing Double Row 3200ATN9 3201ATN9 3202ATN9 3302ATN9

Brand Name:	AWX
Model Number:	3200 ATN9
MOQ:	10pcs
Packaging Details:	carton
Payment Terms:	T/T, L/C, D/P, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ISO

Name:

Angular Contact Ball Bearing Double Row

Availability:

Have Stocks

Double

Part Number:

3200 ATN9

Grease:

Mobil Polyrex EM,Kyodo Yushi SRL

Trade Terms:

FOB,CFR,CIF,EXW

Rolling Element:

Balls

Cage Type:

Pressed Steel Cage

Contact Angle:

Supply Ability:

1000000

Highlight:

High Speed Angular Contact Ball Bearing

Angular Contact Ball Bearing Double Row

3200 ATN9

Product Description

3200ATN9 3201ATN9 3202ATN9 3302ATN9 Mobil Polyrex EM Grease Double Row Angular Contact Ball Bearing

Product Description:

Double row angular contact ball bearings correspond, in their design and operation, to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space. They can operate at high speeds and are more suitable than deep groove ball bearings for supporting large axial forces in both directions

Features:

High-speed capability
Accommodate relatively high radial loads, high axial loads in both directions and tilting moments
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings

Technical Parameters:

Model	Principal dimensions d[in]	Principal dimensions D[in]	Principal dimensions B[in]
3200ATN9	0.394	1.181	0.551
3200ATN9/C3	0.394	1.181	0.551
3201A-2ZTN9	0.472	1.26	0.626
3201ATN9	0.472	1.26	0.626
3202ATN9	0.591	1.378	0.626
3302ATN9	0.591	1.575	0.472
3203ATN9	0.669	1.575	0.689
3303ATN9	0.669	1.85	0.874
3204A	0.787	1.85	0.811
3204A-2RS1	0.787	1.85	0.811
3204A-2Z	0.787	1.85	0.811
3304A	0.787	2.047	0.874
3205A	0.984	2.047	0.811
3205A-2Z	0.984	2.047	0.811
3305A	0.984	2.441	1
3305A-2Z	0.984	2.441	1
etc.

Applications:

Industrial pumps
Industrial gearboxes
Renewable energy
Compressors
Industrial electric motors & generators
Trucks, trailers and buses
Metals

High Speed Angular Contact Ball Bearing Double Row 3200ATN9 3201ATN9 3202ATN9 3302ATN9 5

FAQ:

Q1: What is the brand name of this Angular Contact Ball Bearing?

A1: The brand name of this product is AWX.

Q2: What is the place of origin of this Angular Contact Ball Bearing?

A2: This product is made in China.

Q3: Does this Angular Contact Ball Bearing have any certification?

A3: Yes, this product has CE/ISO certification.

Q4: What is the minimum order quantity for this Angular Contact Ball Bearing?

A4: The minimum order quantity for this product is 10pcs.

Q5: What are the packaging details for this Angular Contact Ball Bearing?

A5: This product is packaged in a carton.

Q6: What is the delivery time for this Angular Contact Ball Bearing?

A6: The delivery time for this product is within 7 days.

Q7: What is the supply ability of this Angular Contact Ball Bearing?

A7: The supply ability of this product is 1000000.
